BAGGERS

CHARACTERISTICS

• Product fed by retracting conveyor belts all the way into the bag
• Start stop infeed for product flow through bagger
• Two bag tables with automatic switching for improved work flow
• Left- or right-hand configurations
• Options: servo retract height control (for stacks over 2.5”), vacuum bag opening (for non-sterile shop air), pneumatic controlled retract antenna (for improved bag tail preparation for sealing), multiple outfeed options to suit your needs

SPECIFICATIONS

• Length: 130” Width: 45” Height: 55”
• Product size: 4” to 16” diameter, stack height up to 5”
• Rates: product dependant, approximately 35 bags per minute
• Electrical: 220V – 10A – 3PH
• Pneumatic: 8CFM @ 80PSI

CHARACTERISTICS

• Product fed by retracting conveyor belts all the way into the bag
• Multi-stage start stop infeed for product flow through bagger
• Operator side bag loading with load/unload bag conveyor
• Left- or right-hand configurations
• Included features: full guarding; adjustable infeed guides and retract plate entry with readouts; servo controlled retract height, antenna and bag clamp for more precise adjustments, bag length adjustment to minimize cycle time

SPECIFICATIONS

• Length: 130” Width: 56” Height: 55”
• Product size: 4” to 14” diameter, stack height up to 5.25”
• Rates: product dependent, up to 45 bags per minute
• Electrical: 220V – 10A – 3PH
• Pneumatic: 6CFM @ 80PSI

CHARACTERISTICS

• Number of lanes can be programmed per product for packaging 4, 5 or 6 products.
• Stainless Steel and anodized aluminium construction.
• Add bags at any time without stopping the machine.
• Servo controlled chute mechanism.
• On the fly lane size changes.
• Optional interchangeable chutes for different product types.
• Start-stop outfeed conveyor included, multiple closure options are available.
• Left- or right-hand configurations.
• Optional dispatch head for systems where bagels arrive in single file.

SPECIFICATIONS

• Length: 150” Width: 73” Height: 55” (includes outfeed conveyor)
• Rate: Up to 50 bags per minute
• Product size: up to 5” diameter for 6 lanes.
• Electrical: 220V – 15A – 3PH
• Pneumatic: 10CFM @ 90PSI

CHARACTERISTICS

• Conceived as a bypass loop to your production line. Either bypass product or transfer into the bagger for bagging 2, 3 or more product into the same bag. All controlled from the machine’s touch screen panel.
• Stainless Steel and anodized aluminium construction.
• Integrated automatic bag changer.
• Optional pushers for different product types.
• Left- or right-hand configurations.
• Optional infeed, outfeed and transfer conveyors for your needs. Easy access retract also available for the outfeed.

SPECIFICATIONS

• Width: 113” Depth: 53” Height: 80” . Depth with typical conveyor layout: 170”
• Rate: 40 bags per minute
• Product size: Total 17.5” wide, 7” high
• Electrical: 220V – 20A – 3PH
• Pneumatic: 8CFM @ 80PSI

CHARACTERISTICS

• One or Two arm configurations
• Pneumatic or servo drive
• Left- or right-hand configurations
• Side feed or front feed
• Multiple infeed options

SPECIFICATIONS

• Width: 65” Depth: 82” Height: 49” (including outfeed conveyor)
• Rate: from 24 bags per minute with 1-arm pneumatic to over 50 bags per minute with 2-arm servo
• Product size: Width 8” x Height 4” (typical, customizable)
• Electrical: 220V – 15A – 3PH
• Pneumatic: 10CFM @ 90PSI
